WITH MANY EXTRAS ALREADY FROM THE FACTORY
Our compactors are equipped as standard with a host of extras that make working more comfortable and safe. For example, the locking joint, the scraper or the tractor tyres (PDH). Naturally, the engine hood and the tank cover are lockable.
| WEIGHTS | ||||
| Operating weight | 13 000 | kg | ||
| Front axle load | 7 000 | kg | ||
| Rear axle load | 6 000 | kg | ||
| ENGINE | ||||
| Power | 115 | kW | 2 100 | rpm |
| DIMENSIONS | ||||
| Total length | 5 775 | mm | ||
| Overall width | 2 285 | mm | ||
| Overall height | 3 080 | mm | ||
| DRIVING FEATURES | ||||
| Speed | 5 – 11.3 | km/h | ||
| Maximum climbing capacity without vibration |
60 | % | ||
| Max climbing capacity with vibration |
50 | % | ||
