QUALITY REALLY CHANGES THE WORLD
The SANY range of telescopic handlers is designed to meet the specific needs of the construction and rental sector. The wide range of SANY telescopic handler types and sizes offers you all the safety, durability and versatility, as well as low cost of ownership, needed to compete in today’s construction market.
| STH1440 | STH1840 | ||
| ENGINE | |||
| Nominal power | 55 / 2 600 | 55 / 2 600 | kW / rpm |
| PERFORMANCE PARAMETERS | |||
| Max lifting capacity | 4 000 | 4 000 | kg |
| Lifting capacity at max height | 3 000 | 2 500 | kg |
| Lifting capacity at maximum reach | 1 250 | 550 | kg |
| Lifting height | 13 970 | 17 550 | mm |
| DIMENSIONS | |||
| Length to front of chassis | 6 160 | 6 200 | mm |
| Overall width | 2 420 | 2 420 | mm |
| Cabin height without rotary | 2 595 | 2 595 | mm |
| Cabin height with rotary | 2 720 | 2 720 | mm |
| Battle | 2 750 | 2 750 | mm |
