STR50C-10

HIGHLIGHTED FEATURES

+ High precision control via
+ the multi-function control lever

+ Seat and second control lever
can be moved laterally

+ Very easy to use touch screen

WITH MANY EXTRAS ALREADY FROM THE FACTORY

The two powerful SANY STR50C-10 tandem rollers come equipped with many extras as standard. For example, vandal protection, a 12 V connection socket and a USB connector are already on board.

WEIGHTS
Operating weight 4 500 kg
Front axle load 2 250 kg
Rear axle load 2 250 kg
ENGINE
Power 36 kW 2 200 rpm
DIMENSIONS
Total length 2 900 mm
Overall width 1 484 mm
Overall height 2 700 mm
DRIVING FEATURES
Speed 12 km/h
Maximum climbing capacity
without vibration
40 %
Max climbing capacity
with vibration
30 %

TANDEM ROLLS THAT REALLY PUT PRESSURE

SANY’s lightweight tandem rollers are characterized by their versatility and cost-effectiveness. Their capabilities come into their own in tasks such as garden construction and landscaping projects, asphalt paving, maintenance work and connection work. Especially in tight spaces and where maximum precision is required, the articulated steering provides excellent maneuverability for precise work. This enables compaction work to be carried out even more economically and productively. Their robust structure, quality materials and easy handling make them ideal for working in such demanding and tough environments as construction and public works.

Multifunction control lever
Multifunction display
Seat with adjustable armrest
Seat can be moved with both control levers
Anti-vandalism protection
12 V connection socket
USB charging socket

Directional and warning indicators
Battery disconnect switch
Seat contact switch
ROPS anti-roll system with integrated seat belt
Back-up alarm
All-round lights
Emergency stop switch
Lockable cover
Articulation lock
Lockable fuel cap
Operating instructions in local language

Scraper
Galvanized fastening rings

Lighting according to StVZO code
