SY35U

HIGHLIGHTED FEATURES

+ 2 additional proportional control circuits with joystick operation
as standard

+ Double-acting hydraulic circuit for
+ quick coupling incl. pipe system

+ Safety valves on boom and arm

+ Air conditioning

SY35U
SY35U - Imagen 2
SY35U - Imagen 3
SY35U - Imagen 4
SY35U - Imagen 5
SY35U - Imagen 6
SY35U - Imagen 7
SKU SY35U Categoría Etiquetas ,

THE LITTLE GIRL WHO CAN DO BIG TASKS

Precise work, high power, progress even when space is at a premium. The SY35U offers everything you would expect from a mini excavator. It is robust, simple and, thanks to its excellent power rating, ideal for all types of excavation work.

DIMENSIONS
Operating weight 3 860 kg
Bucket capacity 0.12 m³
Lunghezza transport 4 915 mm
Long-distance transport 1 720 mm
Overall height 2 515 mm
ENGINE
Power 18.2 kW 2 200 rpm
WORKING RANGE
Max. excavation depth 3 105 mm
Maximum range 5 465 mm
Min. turning radius 2 475 mm
ISO bucket breakout force 30.4 kN
ISO arm pulling force 18.2 kN
HYDRAULIC SYSTEM
Max oil flow 88 l/min

THE SY35U: EXEMPLARY EQUIPMENT INCLUDED AS STANDARD

Productive and concentrated work is only possible when you have the right equipment. The SY35U meets virtually all requirements.

HANDLING COMFORT / CABIN

› Heating
› Manual air conditioning system*
› USB/Bluetooth radio
› Adjustable armrests
› 12 V connection
› Windscreen wipers
› Windscreen washer system
› Additional control circuit 1 on the control lever
› Additional control circuit 2 on the control lever
› 8 pre-set work tools

* Air conditioning contains fluorinated greenhouse gases: Refrigerant type: HFC-134a, Global warming potential: 1 430, Quantity: 0.625 kg, CO 2 e: 0.89 t

SECURITY

› Battery disconnect switch
› Rotating signal lights
› Lockable covers
› Emergency lowering

HYDRAULIC SYSTEM

› Swing brake
› 2 travel speeds
› Hydraulic pre-control of the joystick
› Main filter

WORK LIGHTING

› LED work lights on front roof
› LED work light on boom

LOWER BODY

› Rubber chain
› Cylinder guards – dozer blade
› Tie-down rings

ENGINE COMPARTMENT

› Automatic speed adjustment
› Diesel filter
› Diesel system purge
› Box or compartment for storing grease stain

WORK EQUIPMENT

› Safety valve on boom and arm with overload warning device › Double-acting hydraulic circuit for quick coupling incl. tube system › Hammer installation › Clamp installation › Adjustable oil flow for accessories › Shield › Cylinder protection on the arm
